Feature
• Strong convective systems.
• Atmosphere: N2, H2, RX Gas.
• Rapid heating and cooling rate was due to superior thermal conduction properties.
• Heat: electricity or gas.
Applications
Iron and steel industry
Annealing
• Martensitic stainless steels (SUS4 #) annealing
• Special NiFeCr alloy annealed
• Globular annealing in high carbon alloy steel for
• Normalization and re-crystallization in office. For carbon steel and low alloy steel hardened and tempered
Aluminum
Annealing
• Paper plates and foil
• Capacitor aluminum foil
• Re-heat and quenching
Copper
Bright annealing
• Wire
• Sheet
• Tube plate
Maximum temperature: 850 ℃
Capacity: 6 to 40 tons / furnace
Feature
| Type |
Using size |
Electricity(kw) |
Temperature(Max) |
The maximum capacity of each furnace(KGS/CH) |
| CCB-2020 |
2000X2000H |
240 |
800以上 |
6000 |
| CCB-2420 |
2450X2000 ~ 2400H |
300 |
800以上 |
10000 |
| CCB-2820 |
2800X2000 ~ 2400H |
360 |
800以上 |
16000 |
| CCB-3024 |
3000X2400 ~ 3000H |
390 |
800以上 |
25000 |
| CCB-3430 |
3400X2400 ~ 3000H |
420 |
800以上 |
40000 |
| CCB-4530 |
4500X3000 ~ 4000H |
520 |
800以上 |
45000 |
※ Special size according to customer demand design
