Feature
• With hot air circulation system that allows the furnace atmosphere and temperature uniformity.
• With climate protection, thus, no distortion, no oxidation, save raw materials.
• Cover of using electro-hydraulic lifting devices, lift lid smooth with no jitter.
• Furnace, charging basket, fan and other heat-resistant stainless steel with long service life.
• With rapid cooling, rapid cooling can be based on need.
• With chain protection device to prevent misoperation due to the occurrence of faults and incidents.
• With chain protection device to prevent misoperation due to the occurrence of faults and incidents.
• Nitrogen quality by customers, recognition and recommendation.
Applications
• Die gas nitriding, soft nitriding
• Maximum temperature: 540 ~ 570 ℃
Other Help
Feature
| Type |
Using size |
Electricity(kw) |
| CCD-4580 |
450X800H |
30 |
| CCD-6010 |
600X1000H |
40 |
| CCD-7512 |
750X1200H |
60 |
| CCD-10015 |
1000X1500H |
90 |
| CCD-15020 |
750X1200H |
150 |
※Special size according to customer demand design
