Feature
     •    By Bell furnace and pit furnaces advantages to design and manufacture.
     •    With Bell's strong convection effect, high sealing, and pit of the lower cost.
     •    No need to use protective furnace gas, up to the standard micro-decarburization (refers to low-carbon steel SAE 1018 1022 case size).
     •    With high-speed gas convection, and convection velocity increases with increasing furnace temperature quickly, the heater temperature accuracy up to within 5 ℃, wire annealing microstructure is very uniform.
     •    Control system uses a programmable controller, set the program memory 10, the temperature of the heating, uniform temperature, oil temperature up to a precise calculation PID automatic temperature curve.
     •    Control system is simple easy for staff training, quality and stability. Another design delayed action timer power switch, to facilitate the use of off-peak electricity is not caused by electrical overload.
     •    Power control, mining SCR control, furnace line with high-quality furnace line sheet, life skills.
     •    Forced air cooling system designed to control the cooling rate, in order to facilitate the requirements of different types of lines.
     •    Furnace off high-quality thermal insulation ceramic fiber, high temperature, heat and light weight advantages of saving electricity.
     ※Select the BP-type annealing furnace, on your company reduce costs and improve quality has definitely help to facilitate market advantage. In addition, in view to adopt protective furnace gas such as N2, RX .... 等 furnace gas protection in high carbon steel wire, low alloy steel wire, the company manufacturing various types of gas into a separate furnace, welcome contact with BP-type back stove.

Applications
 • Annealing line for steel, ball handling and design of the new furnace original
• The maximum temperature: 800 ℃
• Capacity: 6 ~ 38 t / a furnace
