Feature
•Anhydrous liquid ammonia to gasification of coal into a gas containing the occurrence of touch controls to 2NH3 → N2 +3 H2 thermal decomposition is relied upon, and further refined.
•Coal combustion in a touch so heated catalytic decomposition of ammonia gas through the cooler, and automatic switching regeneration adsorption drying tower, remove the water, so that the dew point to between minus 40 ~ 60 oC.
Applications
•Stainless steel, tool steel, silicon steel and other non-oxidative heat treatment, copper welding, powder metallurgy and other protective atmosphere
•General reaction: strong reduction
•Gas composition: H2 75%, N2 25%
•Dew point:-20oC ~ -60℃
•Quantity of Gas: 5 ~ 125m3 / H
Other Help
Feature
| Type |
Gas production m3 / H |
Electricity(kw) |
Temperature(Max) |
| CCAX-10 |
5-10 |
20 |
950-1050 |
| CCAX-15 |
10-15 |
30 |
950-1050 |
| CCAX-25 |
20-25 |
45 |
950-1050 |
| CCAX-35 |
30-35 |
45 |
950-1050 |
| CCAX-50 |
40-50 |
60 |
950-1050 |
| CCAX-75 |
60-75 |
75 |
950-1050 |
| CCAX-100 |
80-100 |
90 |
950-1050 |
| CCAX-125 |
110-125 |
120 |
950-1050 |
※ Special size according to customer demand design
